Description
Inlet condition have been designed for - ISO 7183-1986 (E) option B ๏ฌ
Outlet air quality Class - ISO:8573-1:1991 (E) class 3 ๏ฌ
Noise level will be < 70 decibels ๏ฌ
Free from corrosion & scale formation at inner & outer sides ๏ฌ
Uses high strength adsorbent material
Application
Paint spray booths ๏ฌ
Tool, valve, cylinder protection ๏ฌ
Food packaging machine ๏ฌ
Auto garage ๏ฌ
Textile & garment ๏ฌ
SPM ๏ฌ
Instrumentation
Specifications
| Purge loss | 12 ยฑ 1 % |
|---|---|
| Outlet Conditions | Dry air at -20oC PDP* |
| Rated Inlet Pressure | 7 bar (g) |
| Operating Voltage | 85-260 VAC 50 / 60 Hz 1Ph |
| Max Working Pressure | 16 bar (g) |
| Rated Inlet Temperature | 38oC |
